6 Line Common Mode Choke Surface Mount 80 Ohms @ 100 MHz 5A DCR 20mOhm
CM3822R800R-10
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Laird-Signal Integrity Products |
| Series | CM |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 6 |
| Inductance @ Frequency | - |
| Current Rating (Max) | 5A |
| DC Resistance (DCR) (Max) | 20mOhm |
| Voltage Rating - DC | - |
| Voltage Rating - AC | - |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Surface Mount |
| Size / Dimension | 0.385" L x 0.265" W (9.78mm x 6.73mm) |
| Height (Max) | 0.197" (5.00mm) |
| Package / Case | Vertical, 12 Flat Lead |
| Base Product Number | - |
| Impedance @ Frequency | 80 Ohms @ 100 MHz |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | CM3822R151R-00 | CM3822R151R-10 | CM3822R201R-10 | PL8224T |
| Manufacturer | Laird-Signal Integrity Products | Laird-Signal Integrity Products | Laird-Signal Integrity Products | iNRCORE, LLC |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CMC 5A 6LN 150 OHM SMD | CMC 5A 6LN 150 OHM SMD | CMC 5A 6LN 200 OHM SMD | POWER |
| Series | CM | CM | CM | SLIC |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
