CM75TJ-24F
Manufacturer
Powerex Inc.Description
IGBT MOD 1200V 75A 357W
Datasheet
DatasheetPackage
Module
In Stock
73,947 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CM75TJ-24F
CM75TJ-24F
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Trench Three Phase Inverter 1200 V 75 A 357 W Chassis Mount Module
Quick Inquiry
CM75TJ-24F
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Powerex Inc. |
| Series | IGBTMOD™ |
| Packaging | Bulk |
| RoHS Status | |
| IGBT Type | Trench |
| Configuration | Three Phase Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 75 A |
| Power - Max | 357 W |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 75A |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 29 nF @ 10 V |
| Input | Three Phase Bridge Rectifier |
| NTC Thermistor | No |
| Operating Temperature | -40°C ~ 150°C |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | Module |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute | |
|
|
 |
| Part Number | CM75RL-24NF | FF450R33T3E3B5P3BPMA1 | FS200R12KT4RPB51BPSA1 | FF200R12KS4PHOSA1 |
| Manufacturer | Powerex Inc. | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IGBT MOD 1200V 75A 520W | IHV IHM T XHP 3 3-6 5K AG-XHP3K3 | FS200R12 - IGBT MODULE | IGBT MOD 1200V 275A 1400W |
| Series | IGBTMOD™ | XHP™3 | * | - |
| Packaging | Bulk | Tray | Bulk | Tray |
