CNY171S
lmages are for reference only.CNY171S
TRANSISTOR OUTPUT OPTOCOUPLER
Datasheet6-SMD, Gull Wing
54,682 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Transistor with Base Output 5300Vrms 1 Channel 6-SMD
CNY171S
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | Fairchild Semiconductor |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 1 |
| Voltage - Isolation | 5300Vrms |
| Current Transfer Ratio (Min) | 40% @ 10mA |
| Current Transfer Ratio (Max) | 80% @ 10mA |
| Turn On / Turn Off Time (Typ) | 2µs, 3µs |
| Rise / Fall Time (Typ) | 1µs, 2µs |
| Input Type | DC |
| Output Type | Transistor with Base |
| Voltage - Output (Max) | 70V |
| Current - Output / Channel | 50mA |
| Voltage - Forward (Vf) (Typ) | 1.35V |
| Current - DC Forward (If) (Max) | 100 mA |
| Vce Saturation (Max) | 300mV |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, Gull Wing |
| Supplier Device Package | 6-SMD |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | CNY171 | CNY171300 | CNY171300W | CNY1713S |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ||||
| Description | OPTOISO 5.3KV TRANS W/BASE 6DIP | OPTOISO 5.3KV TRANS W/BASE 6DIP | OPTOISO 5.3KV TRANS W/BASE 6DIP | OPTOISO 5.3KV TRANS W/BASE 6SMD |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
