Product CatalogPart Number
CPSQ2418L-502
Manufacturer
CODACADescription
CMC 6.0A 2LN 15K OHM TH
Datasheet
DatasheetPackage
Horizontal, 4 PC Pad
In Stock
91,461 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CPSQ2418L-502
CPSQ2418L-502
lmages are for reference only.Payment Methods
Delivery Services
5 mH @ 1 kHz 2 Line Common Mode Choke Surface Mount 15 kOhms @ 1 MHz 6A DCR 50mOhm
Quick Inquiry
CPSQ2418L-502
Specifications
| Category | Filters - Common Mode Chokes - |
| Manufacturer | CODACA |
| Series | CPSQ2418L |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 5 mH @ 1 kHz |
| Current Rating (Max) | 6A |
| DC Resistance (DCR) (Max) | 50mOhm |
| Voltage Rating - DC | 250V |
| Voltage Rating - AC | - |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Surface Mount |
| Size / Dimension | 1.024" L x 0.945" W (26.00mm x 24.00mm) |
| Height (Max) | 0.610" (15.49mm) |
| Package / Case | Horizontal, 4 PC Pad |
| Base Product Number | - |
| Impedance @ Frequency | 15 kOhms @ 1 MHz |
| Grade | - |
| Qualification | - |
