CR7E-80DB-3.96DS(72)
Manufacturer
Hirose Electric Co LtdDescription
CONN EDGE DUAL 80POS 0.156 T/H
Datasheet
DatasheetPackage
-
In Stock
72,687 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CR7E-80DB-3.96DS(72)
CR7E-80DB-3.96DS(72)
lmages are for reference only.Payment Methods
Delivery Services
80 Position Female Connector Non Specified - Dual Edge Gold 0.156" (3.96mm) Blue
Quick Inquiry
CR7E-80DB-3.96DS(72)
Specifications
| Category | Connectors, Interconnects - Card Edge Connectors - Edgeboard Connectors |
| Manufacturer | Hirose Electric Co Ltd |
| Series | |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Series | CR7 |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | 40 |
| Number of Positions | 80 |
| Card Thickness | - |
| Number of Rows | 2 |
| Pitch | 0.156" (3.96mm) |
| Read Out | Dual |
| Features | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 80.0µin (2.03µm) |
| Contact Type | Full Bellows |
| Color | Blue |
| Flange Feature | - |
| Operating Temperature | -30°C ~ 85°C |
| Material - Insulation | Polycarbonate (PC) |
| Base Product Number | CR7E |
| Termination Rows | 2 |
