CSPSBHC4V8LB-TP
lmages are for reference only.CSPSBHC4V8LB-TP
TVS DIODE 4.8VWM 16VC CSP1006-2
Datasheet0402 (1006 Metric)
57,741 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
16V Clamp 100A (8/20µs) Ipp Tvs Diode Surface Mount CSP1006-2
CSPSBHC4V8LB-TP
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | |
| Type | Zener |
| Bidirectional Channels | 1 |
| Voltage - Reverse Standoff (Typ) | 4.8V (Max) |
| Voltage - Breakdown (Min) | 5V |
| Voltage - Clamping (Max) @ Ipp | 16V |
| Current - Peak Pulse (10/1000µs) | 100A (8/20µs) |
| Power - Peak Pulse | 1600W (1.6kW) |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | 200pF @ 1MHz |
| Operating Temperature | -55°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 0402 (1006 Metric) |
| Supplier Device Package | CSP1006-2 |
| Base Product Number | - |
| Unidirectional Channels | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | CSPSBHC4V5LB-TP | CSPSBHC6V3LB-TP | CSPSBSLC24VAE-TP | CSPSBSLC24VLB-TP |
| Manufacturer | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | ESD PROTECTION DEVICE | TVS DIODE 6.3VWM 16.5VC CSP10062 | TVS DIODES | TVS DIODES |
| Series | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
