CVCO33CL-0559-0561
lmages are for reference only.CVCO33CL-0559-0561
VCO 560MHZ 0.5-4.5V 7.62X7.62MM
Datasheet12-QFN, Variant
62,813 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
560MHz Center Frequency 0.5 V ~ 4.5 V Voltage Controlled Oscillator 2 ±2 dBm -15 2nd Harmonic Typ (dBc)
CVCO33CL-0559-0561
| Category | Crystals, Oscillators, Resonators - VCOs Voltage Controlled Oscillators - |
| Manufacturer | Crystek Corporation |
| Series | CVCO33 |
| Packaging | Strip |
| RoHS Status | ROHS3 Compliant |
| Frequency Range | 559 ~ 561MHz |
| Frequency - Center | 560MHz |
| Voltage - Supply | 5V |
| Tuning Voltage (VDC) | 0.5 V ~ 4.5 V |
| 2nd Harmonic, Typ (dBc) | -15 |
| Icc Max | 15mA |
| Pushing (MHz/V) | 1 |
| Power (dBm) | 2 ±2 |
| Phase Noise Typ (dBc/Hz) | -95 |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 12-QFN, Variant |
| Size / Dimension | 0.300" L x 0.300" W (7.62mm x 7.62mm) |
| Height | 0.079" (2.00mm) |
| Base Product Number | - |
| Product Attribute | |
|
 |
|
| Part Number | CVCO33CL-0559-0561 | CVCO33CL-0559-0561 | CVCO33CL-0110-0150 | CVCO33CL-0110-0150 |
| Manufacturer | Crystek Corporation | Crystek Corporation | Crystek Corporation | Crystek Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | VCO 560MHZ 0.5-4.5V 7.62X7.62MM | VCO 560MHZ 0.5-4.5V 7.62X7.62MM | VCO 130MHZ 0-5V 7.62MM X 7.62MM | VCO 130MHZ 0-5V 7.62MM X 7.62MM |
| Series | CVCO33 | CVCO33 | CVCO33 | CVCO33 |
| Packaging | Strip | Strip | Strip | Strip |
