CY8C21001-24PVXI
lmages are for reference only.CY8C21001-24PVXI
IC MCU 8BIT 8KB FLASH 56SSOP
Datasheet56-BSSOP (0.295", 7.50mm Width)
12,990 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
M8C - Microcontroller IC 8-Bit 24MHz 8KB (8K x 8) FLASH 56-SSOP
CY8C21001-24PVXI
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Cypress Semiconductor Corp |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Core Processor | M8C |
| Core Size | 8-Bit |
| Speed | 24MHz |
| Connectivity | I2C, SPI, UART/USART, USB |
| Peripherals | LCD, POR, PWM, WDT |
| Number of I/O | 26 |
| Program Memory Size | 8KB (8K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 512 x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.4V ~ 5.25V |
| Data Converters | A/D 28x8/10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 56-SSOP |
| Package / Case | 56-BSSOP (0.295", 7.50mm Width) |
| Base Product Number | CY8C21001 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | CY8C21123-24SXI | CY8C21123-24SXIT | CY8C211234-24SXI | CY8C21223-24LGXI |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Cypress Semiconductor Corp |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC MCU 8BIT 4KB FLASH 8SOIC | IC MCU 8BIT 4KB FLASH 8SOIC | PROGRAMMABLE SYSTEM ON A CHIP | IC MCU 8BIT 4KB FLASH 16QFN |
| Series | Infineon Technologies | Infineon Technologies | Infineon Technologies | Cypress Semiconductor Corp |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Bulk |
