D1CSA5931FR003J-T15
lmages are for reference only.D1CSA5931FR003J-T15
RES 0.003 OHM 5% 7W 5931
DatasheetNonstandard
51,134 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
3 mOhms ±5% 7W Chip Resistor Nonstandard Anti-Sulfur, Current Sense, Moisture Resistant, Safety Metal Element
D1CSA5931FR003J-T15
| Category | Resistors - Chip Resistor Surface Mount - |
| Manufacturer | Thin Film Technology Corp. |
| Series | D1CSA |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Resistance | 3 mOhms |
| Tolerance | ±5% |
| Power (Watts) | 7W |
| Composition | Metal Element |
| Features | Anti-Sulfur, Current Sense, Moisture Resistant, Safety |
| Temperature Coefficient | ±50ppm/°C |
| Operating Temperature | -55°C ~ 155°C |
| Package / Case | Nonstandard |
| Supplier Device Package | 5931 |
| Ratings | - |
| Size / Dimension | 0.591" L x 0.305" W (15.00mm x 7.75mm) |
| Height - Seated (Max) | 0.024" (0.60mm) |
| Number of Terminations | 2 |
| Failure Rate | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | D1CSA5931FR001J-T15 | D1CSA5931FR002J-T15 | D1CSA5931M0M20J-T15 | D1CSA5931M0M30J-T15 |
| Manufacturer | Thin Film Technology Corp. | Thin Film Technology Corp. | Thin Film Technology Corp. | Thin Film Technology Corp. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RES 0.001 OHM 5% 10W 5931 | RES 0.002 OHM 5% 8W 5931 | RES 0.0002 OHM 5% 15W 5931 | RES 0.0003 OHM 5% 10W 5931 |
| Series | Thin Film Technology Corp. | Thin Film Technology Corp. | ||
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) |
