D1MPAB2512G0M75FA-T3
lmages are for reference only.D1MPAB2512G0M75FA-T3
RES 0.00075 OHM 1% 2W 2512
DatasheetWide 2512 (6432 Metric), 1225
68,393 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
0.75 mOhms ±1% 2W Chip Resistor Wide 2512 (6432 Metric), 1225 Anti-Sulfur, Current Sense, Flame Retardant Coating, Moisture Resistant, Safety Metal Element
D1MPAB2512G0M75FA-T3
| Category | Resistors - Chip Resistor Surface Mount - |
| Manufacturer | Thin Film Technology Corp. |
| Series | D1MPA |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Resistance | 0.75 mOhms |
| Tolerance | ±1% |
| Power (Watts) | 2W |
| Composition | Metal Element |
| Features | Anti-Sulfur, Current Sense, Flame Retardant Coating, Moisture Resistant, Safety |
| Temperature Coefficient | ±150ppm/°C |
| Operating Temperature | -55°C ~ 170°C |
| Package / Case | Wide 2512 (6432 Metric), 1225 |
| Supplier Device Package | 1225 |
| Ratings | - |
| Size / Dimension | 0.126" L x 0.252" W (3.20mm x 6.40mm) |
| Height - Seated (Max) | 0.049" (1.25mm) |
| Number of Terminations | 2 |
| Failure Rate | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | D1MPAB2512G0M50FA-T3 | D1MPAB2512QR002FA-T4 | D1MPAB2512QR002FAA-T4 | D1MPAB2512QR003FA-T4 |
| Manufacturer | Thin Film Technology Corp. | Thin Film Technology Corp. | Thin Film Technology Corp. | Thin Film Technology Corp. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant | ROHS3 Compliant |
| Description | RES 0.0005 OHM 1% 2W 2512 | RES 0.002 OHM 1% 2W 2512 | RES 0.002 OHM 1% 2W 2512 | RES 0.003 OHM 1% 2W 2512 |
| Series | Thin Film Technology Corp. | Thin Film Technology Corp. | Thin Film Technology Corp. | |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
