D20V0H1U2LP-7B
lmages are for reference only.D20V0H1U2LP-7B
GENERAL PROTECTION PP X1-DFN1006
Datasheet0402 (1006 Metric)
71,618 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
34V Clamp 10A (8/20µs) Ipp Tvs Diode Surface Mount X1-DFN1006-2
D20V0H1U2LP-7B
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 20V (Max) |
| Voltage - Breakdown (Min) | 22V |
| Voltage - Clamping (Max) @ Ipp | 34V |
| Current - Peak Pulse (10/1000µs) | 10A (8/20µs) |
| Power - Peak Pulse | 340W |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | 55pF @ 1MHz |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 0402 (1006 Metric) |
| Supplier Device Package | X1-DFN1006-2 |
| Base Product Number | D20V0 |
| Unidirectional Channels | 1 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | D20V0L1B2LP-7B | D20V0L1B2LP3-7 | D20V0L1B2WS-7 | D20V0L1B2WSQ-7 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TVS DIODE 20VWM 34VC DFN1006-2 | GENERAL PROTECTION PP X2-DFN0603 | TVS DIODE 20VWM 30VC SOD323 | GENERAL PROTECTION PP SOD323 T&R |
| Series | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
