DF3024F25V
lmages are for reference only.DF3024F25V
IC MCU 16BIT 128KB FLASH 100QFP
Datasheet100-BFQFP
58,072 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
H8/300H H8® H8/300H Microcontroller IC 16-Bit 25MHz 128KB (128K x 8) FLASH 100-QFP (14x14)
DF3024F25V
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Renesas Electronics Corporation |
| Series | H8® H8/300H |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Core Processor | H8/300H |
| Core Size | 16-Bit |
| Speed | 25MHz |
| Connectivity | SCI, SmartCard |
| Peripherals | PWM, WDT |
| Number of I/O | 70 |
| Program Memory Size | 128KB (128K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 4K x 8 |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Data Converters | A/D 8x10b; D/A 2x8b |
| Oscillator Type | Internal |
| Operating Temperature | -20°C ~ 75°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 100-QFP (14x14) |
| Package / Case | 100-BFQFP |
| Base Product Number | DF3024 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
|
| Part Number | DF3024FBL25V | DF3024X25V | DF3026X25V | DF3026X25V |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IC MCU 16BIT 128KB FLASH 100QFP | MICROCONTROLLER, 16-BIT, H8/300H | IC MCU 16BIT 256KB FLASH 100TQFP | MICROCONTROLLER, 16-BIT, FLASH, |
| Series | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| Packaging | Tray | Bulk | Tray | Bulk |
