DG508BEQ-T1-E3
lmages are for reference only.DG508BEQ-T1-E3
IC MUX 8:1 380OHM 16TSSOP
Datasheet16-TSSOP (0.173", 4.40mm Width)
17,963 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1 Circuit IC Switch 8:1 380Ohm 16-TSSOP
DG508BEQ-T1-E3
| Category | Integrated Circuits (ICs) - Interface - Analog Switches-Multiplexers-Demultiplexers |
| Manufacturer | Vishay Siliconix |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 8:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 380Ohm |
| Channel-to-Channel Matching (ΔRon) | 10Ohm |
| Voltage - Supply, Single (V+) | 12V ~ 44V |
| Voltage - Supply, Dual (V±) | ±5V ~ 20V |
| Switch Time (Ton, Toff) (Max) | 250ns, 240ns |
| -3db Bandwidth | 250MHz |
| Charge Injection | 2pC |
| Channel Capacitance (CS(off), CD(off)) | 3pF, 13pF |
| Current - Leakage (IS(off)) (Max) | 1nA |
| Crosstalk | -88dB @ 1MHz |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TSSOP |
| Base Product Number | DG508 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
|
| Part Number | DG508BEQ-T1-E3 | DG506AAK/883 | DG506AAK/883 | DG506AAZ/883 |
| Manufacturer | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | IC MUX 8:1 380OHM 16TSSOP | IC MUX 16:1 400OHM 16CERDIP | IC MUX 16:1 400OHM 16CERDIP | IC MUX 16:1 400OHM 20LCC |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tube | Tube |
