DMN3005LK3-13
lmages are for reference only.DMN3005LK3-13
MOSFET N-CH 30V 14.5A TO252-3
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
53,073 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 30 V 14.5A (Ta) 1.68W (Ta) Surface Mount TO-252-3
DMN3005LK3-13
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 14.5A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 5mOhm @ 20A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 4342 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 1.68W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | TO-252-3 |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Base Product Number | DMN3005 |
| Gate Charge (Qg) (Max) @ Vgs | 46.9 nC @ 4.5 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | DMN100-7-F | DMN1003UFDE-13 | DMN1003UFDE-7 | DMN1004UFDF-13 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 30V 1.1A SC59-3 | MOSFET BVDSS: 8V~24V U-DFN2020-6 | MOSFET BVDSS: 8V~24V U-DFN2020-6 | MOSFET N-CH 12V 15A 6UDFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
