DMN32M6LCA8-7
lmages are for reference only.DMN32M6LCA8-7
MOSFET 2N-CH 30V 30A X4-DSN6025
Datasheet8-SMD, No Lead
96,427 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 30V 30A (Ta) 1.1W Surface Mount X4-DSN6025-8
DMN32M6LCA8-7
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel, Common Drain |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 30A (Ta) |
| Rds On (Max) @ Id, Vgs | 2.6mOhm @ 10A, 10V |
| Vgs(th) (Max) @ Id | 2.2V @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs | 42.7nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 2780pF @ 15V |
| Power - Max | 1.1W |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, No Lead |
| Supplier Device Package | X4-DSN6025-8 |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
|
| Part Number | DMN1001UCA10-7 | DMN1002UCA6-7 | DMN1003UCA6-7 | DMN1006UCA6-7 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET 2N-CH 12V 20A X2-TSN1820 | MOSFET 2N-CH X4-DSN3118-6 | MOSFET 2N-CH X3-DSN3518-6 | MOSFET 2N-CH X3-DSN2718-6 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
