DMP2900UWQ-7
lmages are for reference only.DMP2900UWQ-7
MOSFET BVDSS: 8V~24V SOT323 T&R
DatasheetSC-70, SOT-323
75,825 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
P-Channel 20 V 600mA (Ta) 300mW Surface Mount SOT-323
DMP2900UWQ-7
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 600mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 1.8V, 4.5V |
| Rds On (Max) @ Id, Vgs | 750mOhm @ 430mA, 4.5V |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Vgs (Max) | ±6V |
| Input Capacitance (Ciss) (Max) @ Vds | 49 pF @ 16 V |
| FET Feature | - |
| Power Dissipation (Max) | 300mW |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-323 |
| Package / Case | SC-70, SOT-323 |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 0.0007 nC @ 4.5 V |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
 |
|
| Part Number | DMP2900UW-13 | DMP2900UW-7 | DMP2900UWQ-13 | DMP2900UFB-7B |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET BVDSS: 8V-24V SOT323 | MOSFET BVDSS: 8V-24V SOT323 | MOSFET BVDSS: 8V~24V SOT323 T&R | MOSFET BVDSS: 8V~24V X1-DFN1006- |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
