DMP6023LE-13
lmages are for reference only.DMP6023LE-13
MOSFET P-CH 60V 7A/18.2A SOT223
DatasheetTO-261-4, TO-261AA
47,762 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
P-Channel 60 V 7A (Ta), 18.2A (Tc) 2W (Ta) Surface Mount SOT-223-3
DMP6023LE-13
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 7A (Ta), 18.2A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 28mOhm @ 5A, 10V |
| Vgs(th) (Max) @ Id | 3V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 2569 pF @ 30 V |
| FET Feature | - |
| Power Dissipation (Max) | 2W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-223-3 |
| Package / Case | TO-261-4, TO-261AA |
| Base Product Number | DMP6023 |
| Gate Charge (Qg) (Max) @ Vgs | 53.1 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DMP6023LEQ-13 | DMP6023LFG-13 | DMP6023LFG-7 | DMP6023LFGQ-13 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET P-CH 60V 7A SOT223 T&R | MOSFET P-CH 60V 7.7A PWRDI3333-8 | MOSFET P-CH 60V 7.7A PWRDI3333-8 | MOSFET P-CH 60V 7.7A PWRDI3333-8 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
