DRC-0608-822J-UL
lmages are for reference only.DRC-0608-822J-UL
RADIAL INDUCTOR WITH LEADS, 8200
DatasheetRadial, Vertical Cylinder
53,947 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
8.2 mH Unshielded Drum Core, Wirewound Inductor 70 mA 25.2Ohm Max Radial, Vertical Cylinder
DRC-0608-822J-UL
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Signal Transformer |
| Series | DRC-0608 |
| Packaging | Bag |
| RoHS Status | ROHS3 Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 8.2 mH |
| Tolerance | ±5% |
| Current Rating (Amps) | 70 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 25.2Ohm Max |
| Q @ Freq | 70 @ 252kHz |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -20°C ~ 85°C |
| Inductance Frequency - Test | 1 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder |
| Supplier Device Package | Radial, Vertical Cylinder |
| Size / Dimension | 0.295" Dia (7.50mm) |
| Height - Seated (Max) | 0.433" (11.00mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
 |
| Part Number | DRC-0608-822J-UL | DRC-0608-100J-UL | DRC-0608-100J-UL | DRC-0608-101J-UL |
| Manufacturer | Signal Transformer | Signal Transformer | Signal Transformer | Signal Transformer |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RADIAL INDUCTOR WITH LEADS, 8200 | RADIAL INDUCTOR WITH LEADS, 10.0 | RADIAL INDUCTOR WITH LEADS, 10.0 | RADIAL INDUCTOR WITH LEADS, 100H |
| Series | Signal Transformer | Signal Transformer | Signal Transformer | Signal Transformer |
| Packaging | Bag | Bag | Bag | Bag |
