DS1689
lmages are for reference only.DS1689
IC RTC CLK/CALENDAR PAR 28DIP
Datasheet28-DIP (0.600", 15.24mm)
84,721 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Real Time Clock (RTC) IC Clock/Calendar 114B Parallel 28-DIP (0.600", 15.24mm)
DS1689
| Category | Integrated Circuits (ICs) - Clock-Timing - Real Time Clocks |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Series | - |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Type | Clock/Calendar |
| Features | NVSRAM |
| Memory Size | 114B |
| Time Format | HH:MM:SS (12/24 hr) |
| Date Format | YY-MM-DD-dd |
| Interface | Parallel |
| Voltage - Supply | 2.7V ~ 3.3V, 4.5V ~ 5.5V |
| Voltage - Supply, Battery | 2.5V ~ 3.7V |
| Current - Timekeeping (Max) | 2mA @ 3V, 3mA @ 5V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Through Hole |
| Package / Case | 28-DIP (0.600", 15.24mm) |
| Supplier Device Package | 28-PDIP |
| Base Product Number | DS1689 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DS1682S | DS1682S+ | DS1682S+T&R | DS1682S/T&R |
| Manufacturer | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | IC RTC ELAPSED CNT I2C 8SOIC | IC RTC ELAPSED CNT I2C 8SOIC | IC RTC ELAPSED CNT I2C 8SOIC | IC RTC ELAPSED CNT I2C 8SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
