E36D630HPN153MA79M
lmages are for reference only.Payment Methods
Delivery Services
15000 µF 63 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 18.2mOhm @ 120Hz 2000 Hrs @ 85°C
E36D630HPN153MA79M
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | Chemi-Con |
| Series | U36D |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Capacitance | 15000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | 18.2mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 6.15 A @ 120 Hz |
| Ripple Current @ High Frequency | 8.61 A @ 3 kHz |
| Lead Spacing | 0.500" (12.70mm) |
| Size / Dimension | 1.375" Dia (34.93mm) |
| Height - Seated (Max) | 3.125" (79.38mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Base Product Number | - |
| Impedance | - |
| Product Attribute | |
|
|
|
| Part Number | E36D630HPN153MC54M | E36D630HPN154MED0M | E36D630HPN154MED0N | E36D630HLN103MA67U |
| Manufacturer | Chemi-Con | Chemi-Con | Chemi-Con | Chemi-Con |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | |
| Description | CAP ALUM 15000UF 20% 63V SCREW | CAP ALUM 150000UF 20% 63V SCREW | CAP ALUM 150000UF 20% 63V SCREW | CAP ALUM 10MF 20% 63V SCREW CHAS |
| Series | Chemi-Con | Chemi-Con | Chemi-Con | Chemi-Con |
| Packaging | Bulk | Bulk | Bulk | Bulk |
