ECE-P2AA183HA
lmages are for reference only.ECE-P2AA183HA
CAP ALUM 18000UF 20% 100V SNAP
DatasheetRadial, Can - Snap-In - 5 Lead
52,446 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
18000 µF 100 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In - 5 Lead 17mOhm 3000 Hrs @ 105°C
ECE-P2AA183HA
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | Panasonic Electronic Components |
| Series | T-HA |
| Packaging | Bulk |
| RoHS Status | |
| Capacitance | 18000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | 17mOhm |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 8.64 A @ 120 Hz |
| Ripple Current @ High Frequency | 9.936 A @ 10 kHz |
| Lead Spacing | 0.984" (25.00mm) |
| Size / Dimension | 1.969" Dia (50.00mm) |
| Height - Seated (Max) | 3.622" (92.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 5 Lead |
| Base Product Number | ECE-P2 |
| Impedance | - |
| Product Attribute | |
 |
 |
 |
| Part Number | ECE-P2AA123HA | ECE-P2AA153HA | ECE-P2AA223HA | ECE-P2AP103HA |
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| RoHS Status | ||||
| Description | CAP ALUM 12000UF 20% 100V SNAP | CAP ALUM 15000UF 20% 100V SNAP | CAP ALUM 22000UF 20% 100V SNAP | CAP ALUM 10000UF 20% 100V SNAP |
| Series | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Packaging | Bulk | Bulk | Bulk | Bulk |
