LC (Pi) EMI Filter 5th Order Low Pass 4 Channel L = 19nH, C = 12pF 8-UFDFN Exposed Pad
ECLAMP2394P.TCT
| Category | Filters - EMI-RFI Filters LC-RC Networks - |
| Manufacturer | Semtech Corporation |
| Series | EMIClamp® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | RoHS Compliant |
| Type | Low Pass |
| Filter Order | 5th |
| Technology | LC (Pi) |
| Center / Cutoff Frequency | 150MHz (Cutoff) |
| Attenuation Value | 30dB @ 800MHz ~ 2.7GHz |
| Resistance - Channel (Ohms) | 18 |
| Current | - |
| Values | L = 19nH, C = 12pF |
| ESD Protection | Yes |
| Operating Temperature | -40°C ~ 85°C |
| Applications | Data Lines for Mobile Devices |
| Voltage - Rated | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-UFDFN Exposed Pad |
| Size / Dimension | 0.083" L x 0.063" W (2.10mm x 1.60mm) |
| Height | 0.026" (0.65mm) |
| Number of Channels | 4 |
| Base Product Number | ECLAMP2394 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | ECLAMP2394P.TCT | ECLAMP2396P.TCT | ECLAMP2396P.TCT | ECLAMP2398P.TCT |
| Manufacturer | Semtech Corporation | Semtech Corporation | Semtech Corporation | Semtech Corporation |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | ROHS3 Compliant |
| Description | FILTER LC(PI) 19NH/12PF ESD SMD | FILTER LC(PI) 19NH/12PF ESD SMD | FILTER LC(PI) 19NH/12PF ESD SMD | FILTER LC(PI) 19NH/12PF ESD SMD |
| Series | EMIClamp® | EMIClamp® | EMIClamp® | EClamp™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
