ELC-09D102DF
lmages are for reference only.ELC-09D102DF
FIXED IND 1MH 280MA 2.1 OHM TH
DatasheetRadial, Vertical Cylinder
63,488 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1 mH Unshielded Wirewound Inductor 280 mA 2.1Ohm Radial, Vertical Cylinder
ELC-09D102DF
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Panasonic Electronic Components |
| Series | 09D |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 1 mH |
| Tolerance | ±10% |
| Current Rating (Amps) | 280 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 2.1Ohm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | - |
| Inductance Frequency - Test | 10 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder |
| Supplier Device Package | - |
| Size / Dimension | 0.374" Dia (9.50mm) |
| Height - Seated (Max) | 0.350" (8.90mm) |
| Base Product Number | ELC-09 |
| Product Attribute | |
|
 |
 |
| Part Number | ELC-09D102DF | ELC-09D102DF | ELC-09D100DF | ELC-09D100F |
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 1MH 280MA 2.1 OHM TH | FIXED IND 1MH 280MA 2.1 OHM TH | FIXED IND 10UH 2.5A 27 MOHM TH | FIXED IND 10UH 2.5A 27 MOHM TH |
| Series | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Bulk |
