ELVH-F50D-HRRD-C-N2A4
lmages are for reference only.ELVH-F50D-HRRD-C-N2A4
SENSOR 0.1KPA 0.06" 14BIT 8DIP
Datasheet8-DIP (0.504", 12.80mm), Dual Ports, Same Side
71,877 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Pressure Sensor 0.01PSI (0.1kPa) Differential Male - 0.06" (1.6mm) Tube, Dual 14 b 8-DIP (0.504", 12.80mm), Dual Ports, Same Side
ELVH-F50D-HRRD-C-N2A4
| Category | Sensors, Transducers - Pressure Sensors-Transducers - |
| Manufacturer | Amphenol All Sensors Corporation |
| Series | ELV |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Base Product Number | ELVH-F50D |
| Applications | - |
| Pressure Type | Differential |
| Operating Pressure | 0.01PSI (0.1kPa) |
| Output Type | I2C |
| Output | 14 b |
| Accuracy | ±0.25% |
| Voltage - Supply | 2.7V ~ 5.5V |
| Port Size | Male - 0.06" (1.6mm) Tube, Dual |
| Port Style | Barbed |
| Features | Temperature Compensated |
| Termination Style | PC Pin |
| Maximum Pressure | 9.72PSI (67kPa) |
| Operating Temperature | 0°C ~ 50°C |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.504", 12.80mm), Dual Ports, Same Side |
| Supplier Device Package | 8-DIP |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | ELVH-F50D-HRRD-C-N2A5 | ABPLLNN001BG2D3 | ABPLNNN001PG4A3 | DC005NDC4 |
| Manufacturer | Amphenol All Sensors Corporation | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | ||
| Description | SENSOR 0.1KPA 0.06" 14BIT 8DIP | BASIC PRESSURE SENSOR | PRESSURE SENSOR ABP SERIES | SENSOR 0.18PSID 0.19" 4.25V |
| Series | ELV | * | * | DC |
| Packaging | Tray | Bulk | Tray | Tube |
