EMDD100W474M1GV001E
lmages are for reference only.EMDD100W474M1GV001E
CAP CER 0.47UF 10V X7R 1206
Datasheet1206 (3216 Metric)
75,484 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
0.47 µF ±20% 10V Ceramic Capacitor X7R 1206 (3216 Metric)
EMDD100W474M1GV001E
| Category | Capacitors - Ceramic Capacitors - |
| Manufacturer | Johanson Dielectrics Inc. |
| Series | X2Y® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 0.47 µF |
| Tolerance | ±20% |
| Voltage - Rated | 10V |
| Temperature Coefficient | X7R |
| Operating Temperature | -55°C ~ 125°C |
| Features | Low ESL (X2Y) |
| Ratings | - |
| Applications | Bypass, Decoupling |
| Mounting Type | Surface Mount, MLCC |
| Package / Case | 1206 (3216 Metric) |
| Size / Dimension | 0.124" L x 0.063" W (3.15mm x 1.60mm) |
| Height - Seated (Max) | - |
| Thickness (Max) | 0.050" (1.27mm) |
| Lead Spacing | - |
| Lead Style | - |
| Failure Rate | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | EMDD101G102M1GV001E | EMDD101W103M1GV001E | EMDD101W104M1GV001B | EMDD101W104M1GV001E |
| Manufacturer | Johanson Dielectrics Inc. | Johanson Dielectrics Inc. | Johanson Dielectrics Inc. | Johanson Dielectrics Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP CER 1000PF 100V C0G/NP0 1206 | CAP CER 10000PF 100V X7R 1206 | CAP CER 0.1UF 100V X7R 1206 | CAP CER 0.1UF 100V X7R 1206 |
| Series | Johanson Dielectrics Inc. | Johanson Dielectrics Inc. | Johanson Dielectrics Inc. | |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
