Product CatalogPart Number
EMI5206MUTAG
Manufacturer
onsemiDescription
FILTER RC(PI) 100 OHM/7PF SMD
Datasheet
DatasheetPackage
12-UFDFN Exposed Pad
In Stock
70,032 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
EMI5206MUTAG
EMI5206MUTAG
lmages are for reference only.Payment Methods
Delivery Services
RC (Pi) EMI Filter 2nd Order Low Pass 6 Channel R = 100Ohms, C = 7pF 12-UFDFN Exposed Pad
Quick Inquiry
EMI5206MUTAG
Specifications
| Category | Filters - EMI-RFI Filters LC-RC Networks - |
| Manufacturer | onsemi |
| Series | EMI520xMU |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Low Pass |
| Filter Order | 2nd |
| Technology | RC (Pi) |
| Center / Cutoff Frequency | 250MHz (Cutoff) |
| Attenuation Value | 20dB @ 800MHz ~ 5GHz |
| Resistance - Channel (Ohms) | 100 |
| Current | - |
| Values | R = 100Ohms, C = 7pF |
| ESD Protection | Yes |
| Operating Temperature | -40°C ~ 85°C |
| Applications | Data Lines for Mobile Devices |
| Voltage - Rated | - |
| Mounting Type | Surface Mount |
| Package / Case | 12-UFDFN Exposed Pad |
| Size / Dimension | 0.098" L x 0.053" W (2.50mm x 1.35mm) |
| Height | 0.022" (0.55mm) |
| Number of Channels | 6 |
| Base Product Number | EMI5206 |
| Grade | - |
| Qualification | - |
