ESD133C
lmages are for reference only.ESD133C
TVS DIODE 33VWM 60VC DFN1006-2L
Datasheet0402 (1006 Metric)
46,078 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
60V Clamp 4A (8/20µs) Ipp Tvs Diode Surface Mount DFN1006-2L
ESD133C
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | SMC Diode Solutions |
| Series | ESD133C |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 1 |
| Voltage - Reverse Standoff (Typ) | 33V (Max) |
| Voltage - Breakdown (Min) | 35V |
| Voltage - Clamping (Max) @ Ipp | 60V |
| Current - Peak Pulse (10/1000µs) | 4A (8/20µs) |
| Power - Peak Pulse | - |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | 12pF @ 1MHz |
| Operating Temperature | -55°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 0402 (1006 Metric) |
| Supplier Device Package | DFN1006-2L |
| Base Product Number | ESD133 |
| Unidirectional Channels | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | ESD133B1W01005E6327XTSA1 | ESD1014MUTAG | ESD101B102ELE6327XTMA1 | ESD101B102ELSE6327XTSA1 |
| Manufacturer | Infineon Technologies | onsemi | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TVS DIODE 5.5VWM 13VC P/WLL-2-2 | TVS DIODE 3.3VWM 11VC 10UDFN | TVS DIODE 5.5VWM 30VC TSLP-2-20 | TVS DIODE 5.5VWM 30VC TSSLP-2-4 |
| Series | Infineon Technologies | onsemi | Infineon Technologies | Infineon Technologies |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
