25V Clamp 40A (8/20µs) Ipp Tvs Diode Surface Mount DFN3020-10
ESDLC2504P9-TP
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 2.5V (Max) |
| Voltage - Breakdown (Min) | 2.7V |
| Voltage - Clamping (Max) @ Ipp | 25V |
| Current - Peak Pulse (10/1000µs) | 40A (8/20µs) |
| Power - Peak Pulse | 1000W (1kW) |
| Power Line Protection | Yes |
| Applications | General Purpose |
| Capacitance @ Frequency | 3.8pF @ 1MHz |
| Operating Temperature | -55°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 10-UDFN Exposed Pad |
| Supplier Device Package | DFN3020-10 |
| Base Product Number | ESDLC2504 |
| Unidirectional Channels | 8 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
|
| Part Number | ESDLC2504P8-TP | ESDL031-1BF4 | ESDL1531MX4T5G | ESDL20-1BF4 |
| Manufacturer | Micro Commercial Co | STMicroelectronics | onsemi | STMicroelectronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | ESD PROTECTION DEVICE | TVS DIODE 3.3VWM 7VC ST0201 | TVS DIODE 3.3VWM 6.5VC 2X4DFN | DISCRETE |
| Series | Micro Commercial Co | STMicroelectronics | onsemi | STMicroelectronics |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk |
