FCA1206A105M-H3
lmages are for reference only.FCA1206A105M-H3
CAP FILM 1UF 20% 10VDC 1206
Datasheet1206 (3216 Metric)
51,469 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
1 µF Film Capacitor 12V 10V Acrylic, Metallized 1206 (3216 Metric)
FCA1206A105M-H3
| Category | Capacitors - Film Capacitors - |
| Manufacturer | Cornell Dubilier Knowles |
| Series | FCA |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 1 µF |
| Tolerance | ±20% |
| Voltage Rating - AC | 12V |
| Voltage Rating - DC | 10V |
| Dielectric Material | Acrylic, Metallized |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 1206 (3216 Metric) |
| Size / Dimension | 0.126" L x 0.063" W (3.20mm x 1.60mm) |
| Height - Seated (Max) | 0.055" (1.40mm) |
| Termination | Solder Pads |
| Lead Spacing | - |
| Applications | General Purpose |
| Ratings | - |
| Features | Low ESR |
| ESR (Equivalent Series Resistance) | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | FCA1206C154M | FCA1206C154M-H1 | FCA1206C224M | FCA1206C224M-H1 |
| Manufacturer | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP FILM 0.15UF 20% 16VDC 1206 | CAP FILM 0.15UF 20% 16VDC 1206 | CAP FILM 0.22UF 20% 16VDC 1206 | CAP FILM 0.22UF 20% 16VDC 1206 |
| Series | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles |
| Packaging | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) |
