FDI9409 - N-CHANNEL POWERTRENCH
DatasheetTO-262-3 Long Leads, I2PAK, TO-262AA
42,512 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 40 V 80A (Tc) 94W (Tj) Through Hole I2PAK (TO-262)
FDI9409-F085
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Fairchild Semiconductor |
| Series | PowerTrench® |
| Packaging | Bulk |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 40 V |
| Current - Continuous Drain (Id) @ 25°C | 80A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 3.8mOhm @ 80A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 2980 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 94W (Tj) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | I2PAK (TO-262) |
| Package / Case | TO-262-3 Long Leads, I2PAK, TO-262AA |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 56 nC @ 10 V |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
|
 |
 |
| Part Number | FDI9406-F085 | FDI9406-F085 | FDI9406_F085 | FD70N20PWD |
| Manufacturer | onsemi | Fairchild Semiconductor | Fairchild Semiconductor | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | MOSFET N-CH 40V 110A I2PAK | FDI9406 - N-CHANNEL POWERTRENCH | 110A, 40V, 0.0022OHM, N-CHANNEL | MOSFET N-CH 200V 70A TO3P |
| Series | PowerTrench® | PowerTrench® | PowerTrench® | - |
| Packaging | Tube | Bulk | Bulk | Tube |
