FDMF6700
lmages are for reference only.FDMF6700
IC HALF BRIDGE DRVR 25A POWER66
Datasheet40-WFQFN Exposed Pad
95,625 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half Bridge Driver Synchronous Buck Converters DrMOS Power66
FDMF6700
| Category | Integrated Circuits (ICs) - Power Management PMIC - Full Half-Bridge H Bridge Drivers |
| Manufacturer | Fairchild Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Half Bridge |
| Applications | Synchronous Buck Converters |
| Interface | PWM |
| Load Type | Inductive |
| Technology | DrMOS |
| Rds On (Typ) | - |
| Current - Output / Channel | 25A |
| Current - Peak Output | 65A |
| Voltage - Supply | 6.4V ~ 13.5V |
| Voltage - Load | 6.4V ~ 14V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Features | Bootstrap Circuit |
| Fault Protection | Shoot-Through, UVLO |
| Mounting Type | Surface Mount |
| Package / Case | 40-WFQFN Exposed Pad |
| Supplier Device Package | Power66 |
| Base Product Number | FDMF6700 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
 |
| Part Number | FDMF6700 | FDMF6700 | FDMF6700 | FDMF6704 |
| Manufacturer | Fairchild Semiconductor | onsemi | onsemi | Fairchild Semiconductor |
| RoHS Status | ROHS3 Compliant | |||
| Description | IC HALF BRIDGE DRVR 25A POWER66 | IC HALF BRIDGE DRVR 25A POWER66 | IC HALF BRIDGE DRVR 25A POWER66 | IC HALF BRIDGE DRIVER 35A 40MLP |
| Series | - | - | - | XS™ DrMOS |
| Packaging | Bulk | Tape & Reel (TR) | Tape & Reel (TR) | Bulk |
