FH34SW-12S-0.5SH(50)
lmages are for reference only.FH34SW-12S-0.5SH(50)
CONN FFC FPC TOP 12POS 0.5MM R/A
Datasheet-
43,564 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
12 Position FFC, FPC Connector Contacts, Top 0.020" (0.50mm) Surface Mount, Right Angle
FH34SW-12S-0.5SH(50)
| Category | Connectors, Interconnects - FFC-FPC Flat Flexible Connectors - FFC-FPC Flat Flexible Connector Assemblies |
| Manufacturer | Hirose Electric Co Ltd |
| Series | FH34SW |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Flat Flex Type | FFC, FPC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Top |
| Number of Positions | 12 |
| Pitch | 0.020" (0.50mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.039" (1.00mm) |
| Locking Feature | Rotary Lock, Backlock |
| Cable End Type | Tapered |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Housing Material | Liquid Crystal Polymer (LCP), Halogen Free |
| Actuator Material | Polyamide (PA), Nylon, Halogen Free |
| Features | Zero Insertion Force (ZIF) |
| Voltage Rating | 50V |
| Operating Temperature | -55°C ~ 85°C |
| Material Flammability Rating | UL94 HB |
| Current Rating (Amps) | 0.5A |
| Contact Finish Thickness | - |
| Housing Color | Beige |
| Actuator Color | Black |
| Mating Cycles | 20 |
| Base Product Number | - |
| Product Attribute | .jpg "FH34SW-12S-0.5SH(99)") |
 |
|
.jpg "FH34S-11S-0.5SH(50)") |
| Part Number | FH34SW-12S-0.5SH(99) | FH34S-10S-0.5SH(50) | FH34S-10S-0.5SH(99) | FH34S-11S-0.5SH(50) |
| Manufacturer | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd | Hirose Electric Co Ltd |
| RoHS Status | ||||
| Description | CONN FFC FPC TOP 12POS 0.5MM R/A | CONN FFC FPC TOP 10POS 0.5MM R/A | CONN FFC FPC TOP 10POS 0.5MM R/A | CONN FFC FPC TOP 11POS 0.5MM R/A |
| Series | FH34SW | FH34S | FH34S | FH34S |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
