Product CatalogPart Number
FY1113F-TR
Manufacturer
Stanley Electric CoDescription
LED YELLOW DIFFUSED SMD R/A
Datasheet
DatasheetPackage
0805 (2012 Metric)
In Stock
84,773 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FY1113F-TR
FY1113F-TR
lmages are for reference only.Payment Methods
Delivery Services
Yellow 590nm LED Indication - Discrete 1.9V 0805 (2012 Metric)
Quick Inquiry
FY1113F-TR
Specifications
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | Stanley Electric Co |
| Series | 1113F |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | RoHS Compliant |
| Color | Yellow |
| Configuration | Standard |
| Lens Color | White |
| Lens Transparency | Diffused |
| Millicandela Rating | 65mcd |
| Lens Style | Rectangle with Domed Top |
| Lens Size | 1.70mm x 0.60mm |
| Voltage - Forward (Vf) (Typ) | 1.9V |
| Current - Test | 20mA |
| Viewing Angle | 134°, 150° |
| Mounting Type | Surface Mount, Right Angle |
| Wavelength - Dominant | 590nm |
| Wavelength - Peak | 592nm |
| Features | - |
| Package / Case | 0805 (2012 Metric) |
| Supplier Device Package | - |
| Size / Dimension | 2.10mm L x 1.00mm W |
| Height (Max) | 0.60mm |
| Base Product Number | FY1113 |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
|
 |
 |
| Part Number | FY1113F-730-TR | FY1101C-M-TR | FY1101F-TR | FY1104B-TR |
| Manufacturer | Stanley Electric Co | Stanley Electric Co | Stanley Electric Co | Stanley Electric Co |
| RoHS Status | ROHS3 Compliant | |||
| Description | LED YELLOW DIFFUSED 2SMD | LED CLEAR 1608 SMD | LED YELLOW CLEAR SMD R/A | LED YELLOW CLEAR 2PLCC SMD |
| Series | Stanley Electric Co | Stanley Electric Co | Stanley Electric Co | Stanley Electric Co |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
