G7EB-1A-E2 DC24
lmages are for reference only.G7EB-1A-E2 DC24
150A, 800VAC / 60VDC PCB RELAY
Datasheet-
62,995 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay SPST-NO (1 Form A) 12VDC Coil Through Hole
G7EB-1A-E2 DC24
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | Omron Electronics Inc-EMC Div |
| Series | G7EB |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Through Hole |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 100 A |
| Switching Voltage | 800VAC, 60VDC - Max |
| Load - Max Switching | 80000VA, 6000W |
| Coil Current | 235.3 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | - |
| Coil Insulation | - |
| Must Operate Voltage | 9 VDC |
| Must Release Voltage | 0.6 VDC |
| Operate Time | 30 ms |
| Release Time | 10 ms |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | Silver Alloy, Cadmium Free |
| Approval Agency | CQC, TUV, UR |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 51 Ohms |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | G7EB-1A-E DC12 | G7EB-1A-E DC24 | G7EB-1A-E2 DC12 | G7EB-1A DC12 |
| Manufacturer | Omron Electronics Inc-EMC Div | Omron Electronics Inc-EMC Div | Omron Electronics Inc-EMC Div | Omron Electronics Inc-EMC Div |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant |
| Description | RELAY GEN PURPOSE SPST 100A 12V | RELAY GEN PURPOSE SPST 100A 24V | 150A, 800VAC / 60VDC PCB RELAY | RELAY GEN PURPOSE SPST 100A 12V |
| Series | Omron Electronics Inc-EMC Div | Omron Electronics Inc-EMC Div | Omron Electronics Inc-EMC Div | Omron Electronics Inc-EMC Div |
| Packaging | Tray | Tray | Tray | Tray |
