Product CatalogPart Number
H11F2300W
Manufacturer
onsemiDescription
OPTOISOLTR 5.3KV PHOTO FET 6-DIP
Datasheet
DatasheetPackage
6-DIP (0.400", 10.16mm)
In Stock
18,648 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
H11F2300W
H11F2300W
lmages are for reference only.Payment Methods
Delivery Services
Optoisolator MOSFET Output 5300Vrms 1 Channel 6-DIP
Quick Inquiry
H11F2300W
Specifications
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tube |
| RoHS Status | |
| Number of Channels | 1 |
| Voltage - Isolation | 5300Vrms |
| Current Transfer Ratio (Min) | - |
| Current Transfer Ratio (Max) | - |
| Turn On / Turn Off Time (Typ) | 25µs, 25µs (Max) |
| Rise / Fall Time (Typ) | - |
| Input Type | DC |
| Output Type | MOSFET |
| Voltage - Output (Max) | 30V |
| Current - Output / Channel | - |
| Voltage - Forward (Vf) (Typ) | 1.3V |
| Current - DC Forward (If) (Max) | 60 mA |
| Vce Saturation (Max) | - |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | 6-DIP (0.400", 10.16mm) |
| Supplier Device Package | 6-DIP |
| Base Product Number | H11F |
| Grade | - |
| Qualification | - |
