HAT2201WP-EL-E
lmages are for reference only.HAT2201WP-EL-E
15A, 100V, N-CHANNEL MOSFET
Datasheet8-PowerWDFN
56,280 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 100 V 15A (Ta) Surface Mount 8-WPAK
HAT2201WP-EL-E
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Renesas Electronics Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | Not applicable |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 100 V |
| Current - Continuous Drain (Id) @ 25°C | 15A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | - |
| Rds On (Max) @ Id, Vgs | 43mOhm @ 7.5A, 10V |
| Vgs(th) (Max) @ Id | - |
| Vgs (Max) | - |
| Input Capacitance (Ciss) (Max) @ Vds | 1450 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | - |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-WPAK |
| Package / Case | 8-PowerWDFN |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 21 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | HAT2019R-EL-E | HAT2025R-EL-E | HAT2033RJ01-EL | HAT2033RWS-E |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | Not applicable | ROHS3 Compliant | Not applicable | |
| Description | N-CHANNEL POWER MOSFET | N-CHANNEL POWER MOSFET | N-CHANNEL POWER MOSFET | MOSFET N-CH 60V 7A 8SOP |
| Series | * | * | * | - |
| Packaging | Bulk | Bulk | Bulk | Tape & Reel (TR) |
