HC-3/12VDC
lmages are for reference only.HC-3/12VDC
RELAY GEN PURPOSE SPDT 18A 12V
Datasheet-
25,322 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay SPDT (1 Form C) 12VDC Coil Panel Mount
HC-3/12VDC
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | HC, KILOVAC |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Mounting Type | Panel Mount |
| Coil Voltage | 12VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 18 A |
| Switching Voltage | 3500VDC - Max |
| Load - Max Switching | - |
| Coil Current | 150 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | Solder Turret |
| Seal Rating | - |
| Coil Insulation | - |
| Must Operate Voltage | 8 VDC |
| Must Release Voltage | 0.5 VDC |
| Operate Time | 6 ms |
| Release Time | 6 ms |
| Operating Temperature | -55°C ~ 125°C |
| Contact Material | Tungsten (W) |
| Approval Agency | - |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 80 Ohms |
| Base Product Number | 1618274 |
| Product Attribute |  |
 |
 |
|
| Part Number | HC-3 | HC-3/115VDC | DSP1-DC24V-R-F | 2-1393139-2 |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | Panasonic Electric Works | TE Connectivity Potter & Brumfield Relays |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | RELAY GEN PURPOSE SPDT 18A 26.5V | HC-3/115VDC=RELAY, VACUUM, SPD | RELAY GEN PURPOSE DPST 5A 24V | RELAY |
| Series | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | Panasonic Electric Works | TE Connectivity Potter & Brumfield Relays |
| Packaging | Bulk | Bulk | Tube | Bulk |
