HGTG12N60D1D
Manufacturer
Harris CorporationDescription
UFS SERIES N-CHANNEL IGBT
Datasheet
DatasheetPackage
TO-247-3
In Stock
77,322 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
HGTG12N60D1D
HGTG12N60D1D
lmages are for reference only.Payment Methods
Delivery Services
IGBT 600 V 21 A 75 W Through Hole TO-247
Quick Inquiry
HGTG12N60D1D
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Harris Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 21 A |
| Current - Collector Pulsed (Icm) | 48 A |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 12A |
| Power - Max | 75 W |
| Switching Energy | - |
| Input Type | Standard |
| Gate Charge | 70 nC |
| Td (on/off) @ 25°C | - |
| Test Condition | - |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Supplier Device Package | TO-247 |
| Reverse Recovery Time (trr) | 60 ns |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | HGTG12N60A4 | HGTG12N60A4D | HGTG12N60B3 | HGTG12N60C3D |
| Manufacturer | onsemi | onsemi | onsemi | Harris Corporation |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ||
| Description | IGBT 600V 54A 167W TO247 | IGBT 600V 54A 167W TO247 | IGBT 600V 27A 104W TO247 | UFS SERIES N-CH IGBT |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
