HMA121R1
lmages are for reference only.HMA121R1
TRANSISTOR OUTPUT OPTOCOUPLER
Datasheet4-SMD, Gull Wing
40,571 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Transistor Output 3750Vrms 1 Channel 4-SMD
HMA121R1
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | Fairchild Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 1 |
| Voltage - Isolation | 3750Vrms |
| Current Transfer Ratio (Min) | 50% @ 5mA |
| Current Transfer Ratio (Max) | 600% @ 5mA |
| Turn On / Turn Off Time (Typ) | - |
| Rise / Fall Time (Typ) | 3µs, 3µs |
| Input Type | DC |
| Output Type | Transistor |
| Voltage - Output (Max) | 80V |
| Current - Output / Channel | 80mA |
| Voltage - Forward (Vf) (Typ) | 1.3V (Max) |
| Current - DC Forward (If) (Max) | 50 mA |
| Vce Saturation (Max) | 400mV |
| Operating Temperature | -40°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, Gull Wing |
| Supplier Device Package | 4-SMD |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | HMA121R1 | HMA121 | HMA121A | HMA121AV |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ||||
| Description | OPTOISO 3.75KV TRANSISTOR 4SMD | OPTOISO 3.75KV TRANSISTOR 4SMD | OPTOISO 3.75KV TRANSISTOR 4SMD | OPTOISO 3.75KV TRANSISTOR 4SMD |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Box | Box | Box |
