HR1000AGS-P
lmages are for reference only.HR1000AGS-P
RESONANT HALF-BRIDGE CONTROLLER
Datasheet16-SOIC (0.154", 3.90mm Width)
61,967 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Converter Offline Half-Bridge Topology 600kHz 16-SOIC
HR1000AGS-P
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Monolithic Power Systems Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 618V |
| Topology | Half-Bridge |
| Voltage - Supply (Vcc/Vdd) | 8.9V ~ 15.5V |
| Duty Cycle | 50% |
| Frequency - Switching | 600kHz |
| Power (Watts) | - |
| Fault Protection | Current Limiting, Over Temperature, Short Circuit, UVLO |
| Control Features | Frequency Control, Soft Start |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC |
| Mounting Type | Surface Mount |
| Base Product Number | - |
| Voltage - Start Up | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | HR1000AGS | HR1000AGS-Z | HR1002AGSE-P | HR1002AGSE-Z |
| Manufacturer | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC OFFLINE SW HALF-BRDG 16SOIC | IC OFFLINE SW HALF-BRDG 16SOIC | IC OFFLINE SWITCH | IC OFFLINE SWITCH |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
