IL300-F-X019T
lmages are for reference only.IL300-F-X019T
OPTOISO 5.3KV PHVOLT 8SMD
Datasheet8-SMD, Gull Wing
66,029 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Photovoltaic, Linearized Output 4420Vrms 1 Channel 8-SMD
IL300-F-X019T
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | Vishay Semiconductor Opto Division |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 1 |
| Voltage - Isolation | 4420Vrms |
| Current Transfer Ratio (Min) | - |
| Current Transfer Ratio (Max) | - |
| Turn On / Turn Off Time (Typ) | - |
| Rise / Fall Time (Typ) | 1µs, 1µs |
| Input Type | DC |
| Output Type | Photovoltaic, Linearized |
| Voltage - Output (Max) | 500mV |
| Current - Output / Channel | 70µA (Typ) |
| Voltage - Forward (Vf) (Typ) | 1.25V |
| Current - DC Forward (If) (Max) | 60 mA |
| Vce Saturation (Max) | - |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, Gull Wing |
| Supplier Device Package | 8-SMD |
| Base Product Number | IL300 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | IL300-F-X019 | IL300-F-X001 | IL300-F-X006 | IL300-F-X007 |
| Manufacturer | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | OPTOISO 5.3KV PHVOLT 8SMD | OPTOISO 5.3KV PHVOLT 8DIP | OPTOISO 5.3KV PHVOLT 8DIP | OPTOISO 5.3KV PHVOLT 8SMD |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
