Product CatalogPart Number
IMA-S1000-12-YYPLY
Manufacturer
Delta ElectronicsDescription
AC/DC CONVERTER 12V 1000W
Datasheet
DatasheetPackage
-
In Stock
79,004 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
IMA-S1000-12-YYPLY
IMA-S1000-12-YYPLY
lmages are for reference only.Payment Methods
Delivery Services
Enclosed AC DC Converters 1 Output 12V 80 ~ 275 VAC, 120 ~ 300 VDC Input
Quick Inquiry
IMA-S1000-12-YYPLY
Specifications
| Category | Power Supplies - External/Internal (Off-Board) - AC DC Converters - |
| Manufacturer | Delta Electronics |
| Series | IMA-1000 (1000W) |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Type | Enclosed |
| Number of Outputs | 1 |
| Voltage - Input | 80 ~ 275 VAC, 120 ~ 300 VDC |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 6 | - |
| Current - Output 1 | 84 A |
| Current - Output 2 | - |
| Current - Output 3 | - |
| Applications | ITE (Commercial), Medical |
| Voltage - Isolation | 4 kV |
| Efficiency | 93% |
| Operating Temperature | -20°C ~ 70°C (With Derating) |
| Mounting Type | Chassis Mount |
| Size / Dimension | 8.25" L x 5.00" W x 1.60" H (209.6mm x 127.0mm x 40.6mm) |
| Approval Agency | - |
| Minimum Load Required | - |
| Voltage - Output 5 | - |
| Current - Output 4 | - |
| Current - Output 5 | - |
| Power (Watts) | 1000W |
| Features | Adjustable Output, PMBus™, Remote On/Off, Remote Sense, Standby Output |
| Standard Number | - |
| Base Product Number | IMA-S1000 |
| Current - Output 6 | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | IMA-S1000-12-YYPLI | IMA-S1000-24-YYPLI | IMA-S1000-24-YYPLY | IMA-S1000-48-YYPLI |
| Manufacturer | Delta Electronics | Delta Electronics | Delta Electronics | Delta Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | AC/DC CONVERTER 12V 1000W | AC/DC CONVERTER 24V 1000W | AC/DC CONVERTER 24V 1000W | AC/DC CONVERTER 48V 1000W |
| Series | IMA-1000 (1000W) | IMA-1000 (1000W) | IMA-1000 (1000W) | IMA-1000 (1000W) |
| Packaging | Box | Bulk | Box | Box |
