IPN70R900P7SATMA1
lmages are for reference only.IPN70R900P7SATMA1
MOSFET N-CH 700V 6A SOT223
DatasheetTO-261-4, TO-261AA
35,021 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 700 V 6A (Tc) 6.5W (Tc) Surface Mount PG-SOT223
IPN70R900P7SATMA1
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Infineon Technologies |
| Series | CoolMOS™ P7 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 700 V |
| Current - Continuous Drain (Id) @ 25°C | 6A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 900mOhm @ 1.1A, 10V |
| Vgs(th) (Max) @ Id | 3.5V @ 60µA |
| Vgs (Max) | ±16V |
| Input Capacitance (Ciss) (Max) @ Vds | 211 pF @ 400 V |
| FET Feature | - |
| Power Dissipation (Max) | 6.5W (Tc) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-SOT223 |
| Package / Case | TO-261-4, TO-261AA |
| Base Product Number | IPN70R900 |
| Gate Charge (Qg) (Max) @ Vgs | 6.8 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | IPA028N04NM3SXKSA1 | IPA028N08N3GXKSA1 | IPA029N06NM5SXKSA1 | IPA029N06NXKSA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TRENCH <= 40V PG-TO220-3 | MOSFET N-CH 80V 89A TO220-FP | MOSFET N-CH 60V 87A TO220 | MOSFET N-CH 60V 84A TO220-FP |
| Series | OptiMOS™ | OptiMOS™ | OptiMOS™ 5 | OptiMOS™ |
| Packaging | Tube | Tube | Tube | Tube |
