IRFB38N20DPBF
lmages are for reference only.IRFB38N20DPBF
IRFB38N20 - 12V-300V N-CHANNEL P
DatasheetTO-220-3
81,558 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 200 V 43A (Tc) 3.8W (Ta), 300W (Tc) Through Hole TO-220AB
IRFB38N20DPBF
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | International Rectifier |
| Series | HEXFET® |
| Packaging | Bulk |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 200 V |
| Current - Continuous Drain (Id) @ 25°C | 43A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 54mOhm @ 26A, 10V |
| Vgs(th) (Max) @ Id | 5V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 2900 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 3.8W (Ta), 300W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220AB |
| Package / Case | TO-220-3 |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 91 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | IRFB38N20DPBF | IRF100B201 | IRF100B201 | IRF100B202 |
| Manufacturer | Infineon Technologies | Infineon Technologies | UMW | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 200V 43A TO220AB | MOSFET N-CH 100V 192A TO220AB | MOSFET N-CH 100V 192A TO220AB | MOSFET N-CH 100V 97A TO220AB |
| Series | HEXFET® | HEXFET®, StrongIRFET™ | * | HEXFET®, StrongIRFET™ |
| Packaging | Tube | Tube | Tube | Tube |
