IRGR4045DPBF
lmages are for reference only.IRGR4045DPBF
IGBT W/ULTRAFAST SOFT RECOVERY D
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
44,540 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT Trench 600 V 12 A 77 W Surface Mount DPAK
IRGR4045DPBF
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | International Rectifier |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | Trench |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 12 A |
| Current - Collector Pulsed (Icm) | 18 A |
| Vce(on) (Max) @ Vge, Ic | 2V @ 15V, 6A |
| Power - Max | 77 W |
| Switching Energy | 56µJ (on), 122µJ (off) |
| Input Type | Standard |
| Gate Charge | 19.5 nC |
| Td (on/off) @ 25°C | 27ns/75ns |
| Test Condition | 400V, 6A, 47Ohm, 15V |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Supplier Device Package | DPAK |
| Reverse Recovery Time (trr) | 74 ns |
| Base Product Number | IRGR4045 |
| Product Attribute | |
 |
 |
 |
| Part Number | IRGR4045DPBF | IRGR4045DTRLPBF | IRGR4045DTRPBF | IRGR4045DTRPBF |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | International Rectifier |
| RoHS Status | ROHS3 Compliant | |||
| Description | IGBT 600V 12A 77W DPAK | IGBT TRENCH 600V 12A TO252AA | IGBT TRENCH 600V 12A TO252AA | IGBT W/ULTRAFAST SOFT RECOVERY D |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR) | Tape & Reel (TR) | Bulk |
