IRL8114PBF
Manufacturer
International RectifierDescription
MOSFET N-CH 30V 90A TO220AB
Datasheet
DatasheetPackage
TO-220-3
In Stock
75,830 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
IRL8114PBF
IRL8114PBF
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 30 V 90A (Tc) 115W (Tc) Through Hole TO-220AB
Quick Inquiry
IRL8114PBF
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | International Rectifier |
| Series | HEXFET® |
| Packaging | Bulk |
| RoHS Status | Not applicable |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 90A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | - |
| Rds On (Max) @ Id, Vgs | 4.5mOhm @ 40A, 10V |
| Vgs(th) (Max) @ Id | 2.25V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 2660 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 115W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220AB |
| Package / Case | TO-220-3 |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 29 nC @ 4.5 V |
| Grade | - |
| Qualification | - |
