IRSM807-105MH
lmages are for reference only.IRSM807-105MH
IC HALF BRIDGE DRIVER 10A 31PQFN
Datasheet31-PowerVQFN
14,541 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half Bridge Driver AC Motors UMOS 31-PQFN (8x9)
IRSM807-105MH
| Category | Integrated Circuits (ICs) - Power Management PMIC - Full Half-Bridge H Bridge Drivers |
| Manufacturer | Infineon Technologies |
| Series | µIPM™ |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Half Bridge |
| Applications | AC Motors |
| Interface | Logic |
| Load Type | Inductive |
| Technology | UMOS |
| Rds On (Typ) | 580mOhm |
| Current - Output / Channel | 10A |
| Current - Peak Output | - |
| Voltage - Supply | 13.5V ~ 16.5V |
| Voltage - Load | 400V (Max) |
| Operating Temperature | 150°C (TJ) |
| Features | Bootstrap Circuit |
| Fault Protection | UVLO |
| Mounting Type | Surface Mount |
| Package / Case | 31-PowerVQFN |
| Supplier Device Package | 31-PQFN (8x9) |
| Base Product Number | IRSM807 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
|
| Part Number | IRSM807-105MH | IRSM807-105MHTR | IRSM807-105MHTR | IRSM807-105MHTR |
| Manufacturer | Infineon Technologies | International Rectifier | Infineon Technologies | International Rectifier |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IC HALF BRIDGE DRIVER 10A 31PQFN | IC HALF BRIDGE DRIVER 10A 31PQFN | IC HALF BRIDGE DRIVER 10A 31PQFN | IC HALF BRIDGE DRIVER 10A 31PQFN |
| Series | µIPM™ | µIPM™ | µIPM™ | µIPM™ |
| Packaging | Tray | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Bulk |
