Half-Bridge Gate Driver IC Non-Inverting 8-SOIC
ISL6613CBZR5214
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Intersil |
| Series | - |
| Packaging | Tube |
| RoHS Status | Not applicable |
| Driven Configuration | Half-Bridge |
| Channel Type | Synchronous |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 10.8V ~ 13.2V |
| Logic Voltage - VIL, VIH | - |
| Current - Peak Output (Source, Sink) | 1.25A, 2A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 36 V |
| Rise / Fall Time (Typ) | 26ns, 18ns |
| Operating Temperature | 0°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | ISL6613 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | ISL6613CB | ISL6613CBZ | ISL6605CB | ISL6605CB |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Intersil |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant |
| Description | IC GATE DRVR HALF-BRIDGE 8SOIC | IC GATE DRVR HALF-BRIDGE 8SOIC | IC GATE DRVR HALF-BRIDGE 8SOIC | HALF BRIDGE BASED MOSFET DRIVER |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
