IXFH36N60X3
Manufacturer
Littelfuse Inc.Description
MOSFET ULTRA JCT 600V 36A TO247
Datasheet
DatasheetPackage
TO-247-3
In Stock
91,829 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
IXFH36N60X3
IXFH36N60X3
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 600 V 36A (Tc) 446W (Tc) Through Hole TO-247
Quick Inquiry
IXFH36N60X3
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Littelfuse Inc. |
| Series | HiPerFET™, Ultra X3 |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 600 V |
| Current - Continuous Drain (Id) @ 25°C | 36A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 90mOhm @ 18A, 10V |
| Vgs(th) (Max) @ Id | 5V @ 2.5mA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 2030 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 446W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-247 |
| Package / Case | TO-247-3 |
| Base Product Number | IXFH36 |
| Gate Charge (Qg) (Max) @ Vgs | 29 nC @ 10 V |
| Grade | - |
| Qualification | - |
