54F109 - DUAL JK POSITIVE EDGE-T
Datasheet16-CDIP (0.300", 7.62mm)
71,109 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Flip Flop 2 Element JK Type 1 Bit Positive Edge 16-CDIP (0.300", 7.62mm)
JD54F109SEA
| Category | Integrated Circuits (ICs) - Logic - Flip Flops |
| Manufacturer | National Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Function | Set(Preset) and Reset |
| Type | JK Type |
| Output Type | Complementary |
| Number of Elements | 2 |
| Number of Bits per Element | 1 |
| Clock Frequency | 70 MHz |
| Max Propagation Delay @ V, Max CL | 10.5ns @ 5V, 50pF |
| Trigger Type | Positive Edge |
| Current - Output High, Low | 1mA, 20mA |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Iq) | 17 mA |
| Input Capacitance | - |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Supplier Device Package | 16-CDIP |
| Package / Case | 16-CDIP (0.300", 7.62mm) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | JD54F374SRA | JD54F74SCA | JD54F74SDA | JM38510/32501BRA |
| Manufacturer | National Semiconductor | National Semiconductor | National Semiconductor | Texas Instruments |
| RoHS Status | ROHS3 Compliant | |||
| Description | BUS DRIVER, F/FAST SERIES, 1-FUN | 54F74 - DUAL D-TYPE POSITIVE EDG | 54F74 - DUAL D-TYPE POSITIVE EDG | OCTAL D-TYPE FLIP-FLOP WITH CLEA |
| Series | 54F | - | - | 54LS |
| Packaging | Bulk | Bulk | Bulk | Tube |
